SIZE/WEIGHT |
DIMENSIONS |
WIDTH |
1,352 mm (53-1/4″) (Polished finish: 1,355 mm (53-3/8″)) |
HEIGHT |
918 mm (36-1/8″) (Polished finish: 921 mm (36-1/4″)) |
DEPTH |
595 mm (23-7/16″) (Polished finish: 596 mm (23-7/16″)) |
WEIGHT |
WEIGHT |
59.0 kg (130 lbs., 1 oz) (Polished finish: 61.5 kg (135 lbs., 9 oz)) |
CONTROL INTERFACE |
KEYBOARD |
NUMBER OF KEYS |
88 |
TYPE |
GH3X (Graded Hammer 3X) keyboard with synthetic ivory keytops, escapement |
TOUCH SENSITIVITY |
Hard2, Hard1, Medium, Soft1, Soft2, Fixed |
COUNTERWEIGHT |
Yes |
PEDAL |
NUMBER OF PEDALS |
3 |
HALF PEDAL |
Yes |
FUNCTIONS |
Sustain, Sostenuto, Soft, Glide, Song Play / Pause, Style Start / Stop, Volume, etc. |
DISPLAY |
TYPE |
TFT Color LCD |
SIZE |
4.3 inch (480 x 272 dots) |
LCD BRIGHTNESS |
Yes |
COLOR |
Yes |
SCORE DISPLAY FUNCTION |
Yes |
LYRICS DISPLAY FUNCTION |
Yes |
LANGUAGE |
English, Japanese, German, French, Spanish, Italian |
PANEL |
LANGUAGE |
English only |
CABINET |
KEY COVER |
KEY COVER STYLE |
Sliding |
MUSIC REST |
Yes |
VOICES |
TONE GENERATION |
PIANO SOUND |
Yamaha CFX, Bösendorfer Imperial |
KEY-OFF SAMPLES |
Yes |
SMOOTH RELEASE |
Yes |
VIRTUAL RESONANCE MODELING (VRM) |
Yes |
STRING RESONANCE |
VRM |
DAMPER RESONANCE |
VRM |
POLYPHONY |
NUMBER OF POLYPHONY (MAX.) |
256 |
PRESET |
NUMBER OF VOICES |
777 Voices + 29 Drum / SFX Kits + 480 XG Voices |
FEATURED VOICES |
10 VRM Voices, 49 Super Articulation Voices, 23 Mega Voices, 13 Natural! Voices, 26 Sweet! Voices, 58 Cool! Voices, 70 Live! Voices, 20 Organ Flutes! Voices |
CUSTOM |
VOICE EDIT |
Yes |
COMPATIBILITY |
XG, GS (for Song playback), GM, GM2 |
EFFECTS |
TYPES |
REVERB |
58 Preset + 3 User |
CHORUS |
106 Preset + 3 User |
DSP |
295 Preset + 3 User |
MASTER COMPRESSOR |
5 Preset + 5 User |
MASTER EQ |
5 Preset + 2 User |
PART EQ |
27 Parts |
INTELLIGENT ACOUSTIC CONTROL (IAC) |
Yes |
STEREOPHONIC OPTIMIZER |
Yes |
FUNCTIONS |
DUAL/LAYERS |
Yes |
SPLIT |
Yes |
ACCOMPANIMENT STYLES |
PRESET |
NUMBER OF PRESET STYLES |
310 |
FEATURED STYLES |
253 Pro Styles, 21 Session Styles, 36 Pianist Styles |
FINGERING |
Single Finger, Fingered, Fingered On Bass, Multi Finger, AI Fingered, Full Keyboard, AI Full Keyboard |
STYLE CONTROL |
INTRO x 3, MAIN VARIATION x 4, FILL x 4, BREAK, ENDING x 3 |
CUSTOM |
STYLE CREATOR |
Yes |
OTHER FEATURES |
MUSIC FINDER |
1,200 Records |
ONE TOUCH SETTING (OTS) |
4 for each Style |
STYLE RECOMMENDER |
Yes |
FILE FORMAT |
Style File Format GE (Guitar Edition) |
SONGS |
PRESET |
NUMBER OF PRESET SONGS |
65 |
RECORDING |
NUMBER OF TRACKS |
16 |
DATA CAPACITY |
approx. 300 KB / Song |
RECORDING FUNCTION |
Yes |
COMPATIBLE DATA FORMAT |
PLAYBACK |
SMF (Format 0 & 1), XF |
RECORDING |
SMF (Format 0) |
FUNCTIONS |
DEMO |
Yes |
REGISTRATION |
NUMBER OF BUTTONS |
8 |
CONTROL |
Registration Sequence, Freeze |
LESSON/GUIDE |
LESSON/GUIDE |
Follow Lights, Any Key, Karao-Key, Your Tempo |
GUIDE LAMP |
Yes |
PERFORMANCE ASSISTANT TECHNOLOGY (PAT) |
Yes |
PIANO ROOM |
Yes |
USB AUDIO RECORDER |
PLAYBACK |
WAV |
RECORDING |
WAV |
USB AUDIO |
TIME STRETCH |
Yes |
PITCH SHIFT |
Yes |
VOCAL CANCEL |
Yes |
MISCELLANEOUS |
METRONOME |
Yes |
TEMPO RANGE |
Yes |
TRANSPOSE |
Yes |
TUNING |
Yes |
SCALE TYPE |
9 |
STORAGE AND CONNECTIVITY |
STORAGE |
INTERNAL MEMORY |
approx. 2.8 MB |
EXTERNAL DRIVES |
USB Flash Drive |
CONNECTIVITY |
HEADPHONES |
x 2 |
MICROPHONE |
Input Volume, Mic / Line In |
MIDI |
IN / OUT / THRU |
AUX IN |
Stereo mini |
AUX OUT |
L / L + R, R |
AUX PEDAL |
Yes |
USB TO DEVICE |
Yes |
USB TO HOST |
Yes |
AMPLIFIERS AND SPEAKERS |
AMPLIFIERS |
25 W x 2 |
SPEAKERS |
16 cm x 2 |
ACOUSTIC OPTIMIZER |
Yes |
POWER SUPPLY |
POWER CONSUMPTION |
22 W |
ACCESSORIES |
ACCESSORIES |
Owner’s Manual, Data List, “50 Greats for the Piano” Music Book, My Yamaha Product User Registration, AC Power Cord, Bench (included or optional), Holder Set |
